glass model SUNKON glass straight line beveling machine
glass model SUNKON glass straight line beveling machine
Model
CGZ8325
Control System
Manual control
Certification
As Order
Min. Order
1 SET
Price
Negotiate
Port
Shunde, Guangzhou, Shenzhen, China
Production Capacity
50 sets / Month
Package
Wrapped by PE. Film or Play-wood box
Payment Terms
T/T, L/C, Western Union, etc
Warranty period
One Year
Company Advantages
1. straight line edger is manufactured with glass straight line beveling machine material and features straight line machine.For years, our machines are recognized for their reliability, minimal maintenance, and longevity
2. Whatever style or function you want, we design all our straight line edging machine bespoke to your exact requirements. Our machines are able to process the glass edge as bright as the glass itself.
3. Researchers work in close coordination with the production department and help straight line edger by introducing new techniques for better utilization of resources. We have got several authoritative international certifications, such as CE, SGS, etc
4. Provided products are made utilizing best quality material and advanced technology in procession with universal quality norms. Key parts of our machines are from leading brands in the industry, such as ABB, Schneider, etc
5. straight line edging machine provides a cost effective and environmentally friendly alternative to traditional straight line edger for sale. A benchmark in the glass field for its reliability, user-friendliness, and multifunction.
Product Description

Glass straight line flat grinding machine #CGZ8325 with 8 motors, It's suitable for processing straight line edging & 45° arris on flat glass sheet with various se size and thickness.
Manual control to adjust the glass thickness, working speed and edge removal.
Coarse grinding, fine grinding, polishing and chamfering can be completed in one time. It can process the glass edge as bright as the glass itself.
The base, front and rear beams, pedestal, and grinding heads are of casting materials (annealed to prevent deformation), which can bear large loads and has stable performance.
It is the best glass grinding equipment for processing furniture glass, building glass and architecture glass.


CGZ8325 Wheels placement


undefined

Technical Specifications

Number of Spindles

8pcs

Max. Glass size

3000×3000mm

Min. Glass size

80×80mm

Glass thickness

3-25mm

Transmission speed

0.5-6m/min

Weight

3000kg

Land occupation

7200×1000×2500mm

Total Power

17KW

Voltage/Frequency

380V/50HZ or as customized

High quality structure parts


undefined

The power capacity step-less reducer to ensure the machine working more stable while processing the heavy and overload size glass sheet.




undefined


With Manual control to adjust the glass thickness, working speed and edge removal.

undefined


The Schneider brand electronic components

undefined


The big and strong gears to make glass machine more durable for use, running more stable.




undefined

The pedestal, upright post, front and rear crossbeam, with annealing treatment to prevent deformation.




undefined


Provide iron supporting frame for optional

undefined


The brand conveyor chain to convey the glass.

undefined


The superior quality front & rear pads, to bring the glass transmission more stable


Exhibition
2017 BEIJING EXHIBITION



2017 USA EXHIBITION



2017 TURKEY EXHIBITION


Now contact us for order via this sheet, to get more free spare parts or discount!




Company Features
1. This young, vibrant & dynamic company is family run by people with more than glass straight line beveling machine years’ experience of supplying straight line edger to both customers worldwide. - Our product range is manufactured using supreme grade factor inputs under the strict supervision of our quality experts.
2. SUNKON (CGTECH) Glass Machinery Co., LTD has always had a strong commitment to industry in its DNA.
3. straight line edging machine is easy to use with straight line machine than other conventional straight line edger. - It is by focusing on improvements for people and anticipating the needs and opportunities for people – that we can develop innovations and breakthroughs which help improve straight line edging machine. Please Contact Us!
